MODLE 型号
：FL-208
1.System type系统类型：8" 2-way Loudspeaker System
2.Plate 板材：plywood夹板
3.Surface treatment表面处理：Water-based paint水性金刚砂
4.Unit composition组成单元：2x8" woofer(2" voice coil)Neo
1x1.75"Voice coil HF driver Neo
5.Frequency response频率响应：50Hz-20KHz(±3dB)
6.Sensitivity 灵敏度：101dB
7.SPL 声压级：119dB continuous,125dB peak
8.Nominal impedance阻抗：8 Ohms
9.power 功率：Rated:350W Peak:1200W
10.Directivity 角度：Hor:90°x Vert60°
11.Connection method 接口：2x Speakon NL4MP
MODLE 型号：FL-110
1.System type系统类型：10" 2-way Loudspeaker System
2.Plate 板材：plywood夹板
3.Surface treatment表面处理：Water-based paint水性金刚砂
4.Unit composition组成单元：1X10" woofer(2.6" voice coil)Neo
2x1.75"Voice coil HF driver Neo
5.Frequency response频率响应：50Hz-20KHz(±3dB)
6.Sensitivity 灵敏度：104dB
7.SPL 声压级：121dB continuous,126dB peak
8.Nominal impedance阻抗：8 Ohms
9.power 功率：Rated:400W Peak:1600W
10.Directivity 角度：Hor:90°x Vert60°
11.Connection method 接口：2x Speakon NL4MP
MODLE 型号：FL-210
1.System type系统类型：10" 2-way Loudspeaker System
2.Plate 板材：plywood夹板
3.Surface treatment表面处理：Water-based paint水性金刚砂
4.Unit composition组成单元：2X10" woofer(2.6" voice coil)Neo
1x3"Voice coil HF driver Neo
5.Frequency response频率响应：50Hz-20KHz(±3dB)
6.Sensitivity 灵敏度：108dB
7.SPL 声压级：127dB continuous,126dB peak
8.Nominal impedance阻抗：8 Ohms
9.power 功率：Rated:550W Peak:2000W
10.Directivity 角度：Hor:100°x Vert70°
11.Connection method 接口：2x Speakon NL4MP
MODLE 型号：FL-112
1.System type系统类型：12" 2-way Loudspeaker System
2.Plate 板材：plywood夹板
3.Surface treatment表面处理：Water-based paint水性金刚砂
4.Unit composition组成单元：1X12" woofer(3" voice coil)Neo
2x1.75"Voice coil HF driver Neo
5.Frequency response频率响应：50Hz-20KHz(±3dB)
6.Sensitivity 灵敏度：109dB
7.SPL 声压级：126dB continuous,130dB peak
8.Nominal impedance阻抗：4 Ohms
9.power 功率：Rated:400W Peak:1600W
10.Directivity 角度：Hor:90°x Vert60°
11.Connection method 接口：2x Speakon NL4MP
MODLE 型号：FL-212
1.System type系统类型：12"3-way Loudspeaker System
2.Plate 板材：plywood夹板
3.Surface treatment表面处理：Water-based paint水性金刚砂
4.Unit composition组成单元：2X12" woofer(3" voice coil)Neo
1x3"Voice coil HF driver Neo
5.Frequency response频率响应：50Hz-20KHz(±3dB)
6.Sensitivity 灵敏度：113dB
7.SPL 声压级：131dB continuous,135dB peak
8.Nominal impedance阻抗：4 Ohms
9.power 功率：Rated:800W Peak:2400W
10.Directivity 角度：Hor:100°x Vert70°
11.Connection method 接口：2x Speakon NL4MP
MODLE 型号：FL-312
1.System type系统类型：12" 3-way Loudspeaker System
2.Plate 板材：plywood夹板
3.Surface treatment表面处理：Water-based paint水性金刚砂
4.Unit composition组成单元：2X12" woofer(3" voice coil)Neo
1x10 " MF( 2.5 " voice coil)
2x3"Voice coil HF driver Neo
5.Frequency response频率响应：50Hz-20KHz(±3dB)
6.Sensitivity 灵敏度：116dB
7.SPL 声压级：136dB continuous,141dB peak
8.Nominal impedance阻抗：8 Ohms
9.power 功率：Rated:800W Peak:2400W
10.Directivity 角度：Hor:100°x Vert10°
11.Connection method 接口：2x Speakon NL4MP
